The BrainBee OPA-100 is a portable opacimeter designed for measuring the opacity of diesel engine exhaust gases. Compact and lightweight, it offers precise diagnostics essential for vehicle emissions testing.

Key Features

Measurement Range:

• Opacity: 0 to 99.9% (resolution 0.1%)
• Opacity: 0 to 9.99 m?¹ (resolution 0.01 m?¹)
• Engine RPM: 300 to 9990 RPM (resolution 10 RPM)
• Oil Temperature: 20°C to 150°C (resolution 1°C)
• Smoke Temperature: 20°C to 400°C (resolution 1°C)

Connectivity:

• RS-232 and RS-485 serial ports for PC integration
• Optional wireless data transmission via radio
• Compatible with external devices like the MGT-300 EVO for RPM and temperature measurements

Power Supply:

• 12 V DC (11–15 V)
• Power consumption: 1A (5A with heating on)

Operational Features:

• Automatic lens cleaning and auto-zero functions
• Measuring chamber temperature stabilized at 90°C
